Introduction
Embolization is a versatile procedure used in the treatment of a wide range of vascular and non-vascular pathologies. However, potential complications are also complex and varied. The success rate of hepatic embolization can be as high as 86%, while the associated morbidity can reach up to 58%, usually related to bile leaks, hepatic abscesses, or necrosis1. Migration of coils or clips used in surgical procedures into the biliary tract has been reported in the literature, typically as a result of necrosis or fistulization of adjacent structures. Other theories include bacterial or fungal superinfection of pseudoaneurysms and coils, leading to subsequent inflammation and erosion2-5.
Presentation of cases
Case 1
This is a 60-year-old male patient who presented in 2018 with recurrent choledocholithiasis (history of cholecystectomy in 2012). He underwent endoscopic retrograde cholangiopancreatography (ERCP) and biliary stent insertion due to a mismatch between the size of the stones and the distal biliary tract. Furthermore, three additional endoscopic procedures were performed without achieving complete stone removal. In January 2019, the patient consulted for an episode of cholangitis, which was managed with percutaneous biliary drainage. As a late complication, a pseudoaneurysm of the right hepatic artery developed, requiring emergent embolization with coils. In February 2019, he underwent open biliary exploration, sphincterotomy, and sphincteroplasty. He reconsulted in 2020 for residual choledocholithiasis and required endoscopic drainage and biliary stent insertion on two occasions.
In May 2022, the patient presented with jaundice. An ERCP was performed, revealing a 15 mm stone in the left hepatic lobe, which could not be extracted. Therefore, electrohydraulic lithotripsy via choledochoscopy was scheduled. During this procedure, multiple choledocholithiasis was identified in relation to migrated foreign bodies (coils) in the biliary duct (Figures 1 and 2). The stones and most of the visible coils were successfully removed, a biliary stent was left, and a new endoscopic procedure was scheduled. However, the patient reconsulted for another episode of cholangitis, and a medical board decided to perform a biliary-enteric bypass as definitive management.
Figure 1 Fluoroscopic view, foreign bodies (coils) within the biliary tract (arrow). The image is the property of the authors.
Case 2
This is a 54-year-old female patient who underwent laparoscopic cholecystectomy in 2022, resulting in bile duct injury and a biliary fistula. Postoperatively, she required ERCP and stent insertion, as well as management of haemobilia with hemodynamic repercussions secondary to a pseudoaneurysm of the right hepatic artery, which required emergency embolization with coils. She was admitted to the gastroenterology service for a scheduled ERCP and biliary stent removal eight months after the initial procedure. Fluoroscopic imaging revealed a linear foreign body within the biliary tract, which was successfully extracted using a Dormia basket (coils) (Figure 3).
Discussion
The migration of intravascular coils into the biliary tract is uncommon and may promote stone formation, increasing the risk of cholangitis, recurrent abdominal pain, and biliary strictures6. Their extraction has been described in the literature in several case reports using conventional endoscopic methods, percutaneous approaches, or surgical techniques5-9. However, due to the low frequency of this complication, evidence and information are limited, and therefore, management must be individualized based on the patient’s symptoms, clinical course, and anatomy10-12.
Endoscopic extraction through ERCP is ideal in the absence of anatomical alterations such as biliodigestive bypass or gastrectomy. Nevertheless, it is important to consider that fluoroscopic imaging may not always allow for the identification of foreign bodies, which are often embedded within stones and may present clinically as recurrent choledocholithiasis, as described in the first case.
Cholangioscopy using the Spyglass® system, through direct visualization of the biliary tract, allows not only for confirmation of the diagnosis but also for treatment, either through ERCP or via the percutaneous (transhepatic) route. It has become the endoscopic technique of choice for the extraction of foreign bodies from the biliary tract and for addressing associated secondary conditions such as choledocholithiasis13. However, surgical management may be required in some cases if definitive resolution is not achieved with this method.
Conclusions
The migration of foreign bodies into the biliary tract is unusual and serves as a contributing factor to stone formation and other complications. Clinical presentation is similar to that of primary or secondary biliary obstruction due to choledocholithiasis, and endoscopic extraction, whenever possible, is the treatment of choice.
